Hi Mattia,

I think openmpi provides a “ompi_info” command that should print out all information on how it was built. Somewhere in there should have the compiler version.
*********************************************
Adam Reyes

Code Group Leader, Flash Center for Computational Science
Research Scientist, Dept. of Physics and Astronomy
University of Rochester
River Campus: Bausch and Lomb Hall, 369
500 Wilson Blvd. PO Box 270171, Rochester, NY 14627
Email adam.reyes at rochester.edu
Web https://flash.rochester.edu
 (he / him / his)

*********************************************

> On Feb 7, 2024, at 11:45 AM, Mattia Cipriani <mattia.cipriani at enea.it> wrote:
>
> Hi Adam,
>
> thank you for the reply.
> I was aware that this might be the problem, but I don’t know how to check it.
> How can I know which is the version of the compiler used for building the mpi library?
>
> ---------------------------------------------
>   Dr Mattia Cipriani, PhD
>     ENEA
>     FSN-PLAS-PAX
>     45, Via E. Fermi
>     00044 Frascati (Rome)
>     Italy
>     Office:  Building 12
>                 Room 12223
>     Tel:       +39 069400 5145
>     Mobile: +39 328 5552077
>     Skype:  matcipriani
>     Researchgate <https://urldefense.com/v3/__https://www.researchgate.net/profile/Mattia-Cipriani-2__;!!CGUSO5OYRnA7CQ!aazmSSqcrCVxyt9iupeL-dXWjtLDp4mgnGfpdRHPDGN1AXkNZIlpwgoCGjMq3bmNkVsWzm6yxMBbPjxv4Og_PBsmxR3d7uw$>
>     LinkedIn <https://urldefense.com/v3/__https://www.linkedin.com/in/mattia-cipriani-0707bb2a/__;!!CGUSO5OYRnA7CQ!aazmSSqcrCVxyt9iupeL-dXWjtLDp4mgnGfpdRHPDGN1AXkNZIlpwgoCGjMq3bmNkVsWzm6yxMBbPjxv4Og_PBsmKaabxww$>
>     ResearcherID AAG-9269-2021 <https://urldefense.com/v3/__https://publons.com/researcher/AAG-9269-2021/__;!!CGUSO5OYRnA7CQ!aazmSSqcrCVxyt9iupeL-dXWjtLDp4mgnGfpdRHPDGN1AXkNZIlpwgoCGjMq3bmNkVsWzm6yxMBbPjxv4Og_PBsmvZhY6Ck$>
>     ORCID 0000-0002-2500-605X <https://urldefense.com/v3/__https://orcid.org/0000-0002-2500-605X__;!!CGUSO5OYRnA7CQ!aazmSSqcrCVxyt9iupeL-dXWjtLDp4mgnGfpdRHPDGN1AXkNZIlpwgoCGjMq3bmNkVsWzm6yxMBbPjxv4Og_PBsmlFo2Oo8$>
> ---------------------------------------------
>
>
>
>
>> Il giorno 7 feb 2024, alle ore 11:30, Reyes, Adam <adam.reyes at rochester.edu> ha scritto:
>>
>> Hi Mattia,
>>
>> The warning suggests that compiler that you’re using for FLASH is different from the one used to compile the openmpi library. You could check that “mpif90 --version” returns the same GCC 7.3.0 version your warning says that openmpi was built with.
>>
>> It’s difficult to say if this is related to your seg fault or not without more context about where the error is occurring, either from the stdout or the log file.
>> *********************************************
>> Adam Reyes
>>
>> <FLASH.jpg>
>> Code Group Leader, Flash Center for Computational Science
>> Research Scientist, Dept. of Physics and Astronomy
>> University of Rochester
>> River Campus: Bausch and Lomb Hall, 369
>> 500 Wilson Blvd. PO Box 270171, Rochester, NY 14627
>> Email adam.reyes at rochester.edu
>> Web https://flash.rochester.edu
>>  (he / him / his)
>> <FLASH-pride-sml.png>
>>
>> *********************************************
>>
>>
>>
>>> On Feb 7, 2024, at 11:06 AM, Mattia Cipriani <mattia.cipriani at enea.it> wrote:
>>>
>>> Hi,
>>>
>>> I am recently experiencing some issues with FLASH 4.7.1 simulations, after updating from FLASH 4.5.
>>> I am using the same site-specific Makefile.h which was working before, since the configuration of the cluster did not change from the past.
>>> Also the compilers are the same as before.
>>> I use the setup script to collect all the needed files and objects for compiling the simulation and then I use make to compile it.
>>> At the end of the execution of make, I get the following warning
>>>
>>> /bin/ld: warning: libgfortran.so.4, needed by /usr/mpi/gcc730/openmpi-3.1.2/lib/libmpi_usempif08.so, may conflict with libgfortran.so.3
>>>
>>> If I run the flash4 executables with mpirun it starts to run ok, but at some apparently random point of the simulation I get a segmentation fault error.
>>>
>>> I am wondering if the warning from make could be the reason for the segmentation fault error.
>>> How can I solve the warning?
>>> I know it is a linux-related question rather than a FLASH problem, but I would be glad if you can help or at least give me a feedback if the segmentation fault error might be due to the warning from make.
>>>
>>> Best regards,
>>> Mattia
>>>
>>>
>>>
>>>
>>>
>>>
>>>
>>>
